SDMP3: Modular Core Security Ceiling Diffuser
Product Overview
KEES ceiling-mounted security diffusers with a modular core and risk-resistant perforated face provide airflow in secure settings. Surface mount or install in lay-in ceilings. Common applications include behavioral health facilities, correctional facilities, and hospitals.
Materials
Various gauges of steel | Stainless steel | Aluminum
Finishes
Painted—standard and custom colors | Satin polish (stainless steel & aluminum)
Face Configurations
Passageway (V, Z, or W) | Perforated | Lattice
Diffuser Style
Modular | Louvered | Curved blade
Size
Single pieces up to 24" x 24" | Custom sizes available upon request
Throw Patterns
1-, 2-, 3-, or 4-way
Mounting Options
Tamper-resistant security screws through faceplate | Rear mounting angles | Lay-in (drop-in or lock down)
Additional Options
Volume dampers | Screens (woven mesh, bird and insect) | Integrated security grate in sleeve | Square to round transitions| Plenums | Hinged or removable faces | Filter frames
